Sine wave

A general sine source.

Collaboration diagram for Sine wave:

Sine is a trigonometric function (function of an angle). The sine function gives the ratio of the length of the side opposite to an angle, to the length of the hypotenuse.

Two sine functions demonstrating the principles of bias and phase margin.

The bias represents the offset from zero to the average value of the sine function. The phase margin is the angle between the two sine waves. In the figure above, the phase margin is set to pi/2 and the bias is set to 0.5.

Author

Vegar Johansen

Karl-Johan Reite

Date

10.07.2007 VJ: Initial version.

16.02.2011 KJR: Rewritten as part of porting to FSim 2.0

19.07.2011 KGA: Added documentation

Example configuration excerpt

<Lib
  LibName   = "fhsim_base"
  SimObject = "Src/Sine"
  Name      = "sine"
  PortWidth = "2"
  Amplitude = "1,2"
  PhaseRad  = "0.1,0.2"
  PeriodS   = "1,2"
  Bias      = "0,0"
  StartTime = "0,1"
  StopTime  = "10,12"
/>

Input Ports

This function has no inputs.

Output Ports

Name	Width	Description
Out	<PortWidth>	The sine signal
OutDot	<PortWidth>	The derivative of the sine signal

Configuration parameters

Name	Width	Description
PortWidth		The number of elements in the signal.
Amplitude	<PortWidth>	The signal amplitude
PhaseRad	<PortWidth>	The phase of the signal in radians
PhaseDeg	<PortWidth>	The phase of the signal in degrees
FHz	<PortWidth>	The signal frequency [Hz]. This parameter is overridden by PeriodS
PeriodS	<PortWidth>	Period of the signal (sec). Overrides parameter FHz
Bias	<PortWidth>	The amplitude bias (offset from zero to the mean value of the sine wave)
StartTime	<PortWidth>	The time to start the step. This may either be a scalar, or a comma separated list referring to the different elements of the signal.
StopTime	<PortWidth>	The time to stop the step. This may either be a scalar, or a comma separated list referring to the different elements of the signal. If this is negative, this is a true step function with unlimited duration. If it is larger than zero, it is a pulse function, which goes back to the StartValue after the StopTime.

Initial conditions

This SimObject contains no initial conditions.

Full example file

<Contents>
  <OBJECTS>
    <Lib
        LibName="base"
        SimObject="Src/Sine"
        Name="A"
        PeriodS="6.28318530718"
        PhaseRad ="0"
    />
  </OBJECTS>

  <INTERCONNECTIONS>
    <Connection
    />
  </INTERCONNECTIONS>

  <INITIALIZATION>
    <InitialCondition
    />
  </INITIALIZATION>

  <INTEGRATION>
    <Engine
    IntegratorMethod="2"
    NumCores="1"
    TOutput="0, 0:0.5:10, 30"
    LogStates ="1"
    stepsize ="0"
    HMax="0.002"
    HMin="0.00000001"
    AbsTol="1e-3" RelTol="1e-3"
    UseRSSNormInsteadOfInfNorm="0"
    FileOutput="objects:all"
    />
  </INTEGRATION>
</Contents>

This SimObject is referred to as Src/Sine
